Paving Brick Mould

A model of German "craftsmanship"

We can provide high-quality moulds for all types of concrete forming equipment around the world:

State-of-the-art material cutting technology

● Narrowing of web thickness possible

● Optimal tool development

● Machine-dependent presser foot clearance of 0.2-0.5 mm

● Reverse tapered sidewalls possible

● No fixing grooves required

● Typical design for stacking production machines

● Optional draw plate design

● Digital free-form surface design possible

● Heatable presser foot design possible

The most advanced material processing technology

● Suitable for all contours and geometries

● Mould frame tolerance +/- 0.3 mm

● Machine-related presser foot clearance 0.2-0.5 mm

● Precise verticality, corners and smooth side walls

● Easy demoulding

● High-precision fit

● All possible gap holder designs are possible

● Optional design with drawer

● Digital free-form design possible

● Heatable presser foot design is possible

Carburizing treatment (62-68 HRC)

● Mould frame and presser foot hardened (62-68 HRC)

● Min. hardening depth 1.2mm

Nitriding treatment (62-68 HRC)

● Mould frame and presser foot nitrified (62-68 HRC)

● Minimum hardening depth 0.4 mm

● Almost no internal stress compared to carburized moulds

● Smaller web thickness recommended

● Higher contour accuracy than case-hardened moulds

According to customer requirements, moulds can be designed and manufactured by welding or modular thread locking.
